New – Open box Omega DMD4380-DC Isolated Transmitter, 0-50VDC In, 0-10VDC Out, 9-30VDC/10-32VAC
$495.00 USD
Shipping calculated at checkout.
Warranty Terms and Conditions
We have 1 in stock!

Not finding what you need?‎ ‎ Let us find it!

Next Day Automation is NOT an authorized distributor for OMEGA. The Original Manufacturer's warranty may not apply. This is a surplus item.

Product Description

Item Condition: New – Open box
SKU: SB-195797
ST68-3-J

From our inventory we are selling a Omega DMD4380-DC Isolated Transimtter, 0-50VDC In, 0-10VDC Out, 9-30VDC/10-32VAC.

Specifications:

  • Model #:  DMD4380-DC
  • More Information:
    • OMEGA Engineering Low Voltage Isolated DC to DC Signal Conditioner
    • DC Input Ranges:
      • Voltage: 0-10mV to 0-50V
      • Bipolar Voltage: ±50mV to ±10V
      • Current: 0-200uA to 0-50mA
    • DC Output Ranges:
      • Voltage: 0-1 to 0-10V (10mA Max)
      • Bipolar Voltage: ±5 to ±10V (10mA Max)
      • Current: 0-2mA to 0-25mA
    • Output Loop Power Supply: 20 VDC , 25mA
    • Supply Voltage: 9-30 VDC / 10-32 VAC
    • Connections: 4x 4-Terminal Removable Connectors, 14 AWG Max
    • Mounting: DIN 35 Rail
