Used Absolute Process Instruments API 4380 DIN Wide Ranging DC/DC Isolater, 0-10VDC
$275.00 USD
Shipping calculated at checkout.
Warranty Terms and Conditions
We have more than 5 in stock!

Not finding what you need?‎ ‎ Let us find it!

Next Day Automation is NOT an authorized distributor for API. The Original Manufacturer's warranty may not apply. This is a surplus item.

Product Description

Item Condition: Used
SKU: SB-133428
ST32-4-A

From our online storeinventory, we are selling a Absolute Process Instruments API 4380 DIN Wide Ranging DC/DC Isolater, 0-10VDC.

Specifications:

  • Model #: API 4380 DIN
  • More Information:
    • Absolute Process Instruments Wide Ranging DC/DC Isolater
    • Input Ranges:
      • Voltage: 0-50 MVDC Minimum, 0-10VDC Maximum
      • Bipolar Voltage: ñ50VDC Minimum, ñ10VDC Maximum
      • Current: 0-1 mADC Minimum, 0-20mADC Maximum
    • Output Ranges:
      • Voltage: 0-1VDC Minimum, 0-10VDC Maximum
      • Bipolar Voltage: ñ1VDC Minimum, ñ10VDC Maximum
      • Current (20V Compliance): 0-2mADC Minimum, 0-20mADC Maximum, 1000O at 20mA Load Factor
    • Output Linearity: Better than ñ0.1% of span
    • Output Ripple and Noise: Less than 10MVRMS
    • Response Time: Standard 100ms Typical
